Dot‑free, low‑glare task & ambient lighting for custom furniture. Door sensorPIRDim/CCT supported. Rapid prototyping, stable mass production.
| Model | Size | 电压 | 色温 | 显色指数 | Mounting | Typical Power | 资料下载 |
|---|---|---|---|---|---|---|---|
| B010130BB1LZ | 1163×10×9 mm | 12V (24V on request) | 3000K (2700–4000K available) | Ra≥80 (Ra≥90 optional) | Clips / tape / screws | ~7.1 W/pc (based on lab sample measurement) | Test Report (PDF) |
Note: power & luminous data are from lab sample; production specs follow the confirmed BOM and validation.
Use COB or high‑density LEDs with a milky diffuser. Keep diffuser thickness ≥1.0 mm and spacing ≥3–5 mm.
Yes. We supply NC/NO door switches and PIR/microwave motion modules for low‑voltage plug‑and‑play.
Yes. 2700–5000K, Ra≥80/90. Tight binning SDCM≤3 for color consistency.
Use side‑exit/end‑exit cables with slim connectors, or reserve a wire channel inside the aluminum profile.
